Product series
PH216S
Applications
Construction Equipment Vehicles & Road Machines

MultiFaster, high pressure version, 2 lines size 16.

New multi-connection system specifically designed to withstand high pressure applications (46 MPa). Equipped with 2 lines size 16. Black cataphoresis plates with Zn-Ni plated carbon steel handle and cams.
Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings
25 1" PH216S-2-1G F C
Specs
2 x Couplings 1":BSPP 1" FEMALE - ISO 1179-1
Flow Rate: 150 (l/min) at 0.2 MPa 39.626 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 9021 g 19.89 lb
2 2

Male

Filter items
Units
PartNumber Specs Housings Couplings
25 1" 3PH216S-2-1G M C
Specs
2 x Couplings 1":BSPP 1" FEMALE - ISO 1179-1
Flow Rate: 150 (l/min) at 0.2 MPa 39.626 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 5500 g 12.13 lb
2 2
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
16 25 1" 3P 46 MPa 6671.736 psi 150 39.626 0.03 138 MPa 20015.208 psi 138 MPa 20015.208 psi 138 MPa 20015.208 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 1000 (ZnNi) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
