Product series
P608G
Applications
Agriculture Construction Equipment Vehicles & Road Machines

MultiFaster 6 lines, size 08, "G" type, with greaser and Zinc-Nickel plating.

Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings
12,5 1/2" 2P608G-4-E F C
Specs
4 x Couplings 1/2":M24x1,5 MALE 16S - ISO 8434-1-S
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 5055 g 11.14 lb

For more information contact us: [email protected]
* Max. grease volume to insert into the plate: 30 cc. Use of a PTFE-based grease is recommended.
6 4
12,5 1/2" 2P608G-6-12G FC
Specs
6 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
* Max. grease volume to insert into the plate: 35 cc. Use of a PTFE-based grease is recommended.
6 6

Male

Filter items
Units
PartNumber Specs Housings Couplings
12,5 1/2" 2P608G-6-12G MC
Specs
6 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2584.1 g 5.7 lb

For more information contact us: [email protected]
6 6
12,5 1/2" 3P608G-4-E M C
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 4
12,5 1/2" 3P608G-6-12G MC
Specs
6 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 6
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
08 12.5 1/2" 25 MPa 3625.943 psi 70 18.492 0.01 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 1000 (ZnNi) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
