Product series
P608
Applications
Agriculture Construction Equipment Vehicles & Road Machines

MultiFaster 6 lines, size 08.

Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings Electrical Contacts
12,5 1/2" 2P608-1-5-12GFC
Specs
5 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 5 1
12,5 1/2" 2P608-2-4-12GFC
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
2 Electrical Contacts :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 4 2
12,5 1/2" 2P608-4-12S F C
Specs
4 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4475.6 g 9.87 lb

For more information contact us: [email protected]
6 4
12,5 1/2" 2P608-6-12G F C
Specs
6 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4838.8 g 10.67 lb

For more information contact us: [email protected]
6 6
12,5 1/2" 2P608-6-12S F C
Specs
6 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3904.6 g 8.61 lb

For more information contact us: [email protected]
6 6
12,5 1/2" 2P608-6-34S F C
Specs
6 x Couplings 1/2":1 - 1/16" - 12 UN FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 5082.2 g 11.2 lb

For more information contact us: [email protected]
6 6
12,5 1/2" 2P608-A-5-12GFC
Specs
5 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :7 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 5 1
12,5 1/2" 2P608-B-4-C F C
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
2 Electrical Contacts :7 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 4 2
12,5 1/2" 3P608-6-12G F C
Specs
6 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4804 g 10.59 lb

For more information contact us: [email protected]
* This part number is equipped with a shorter lever (R250 mm instead of R318 mm)
6 6

Male

Filter items
Units
PartNumber Specs Housings Couplings Electrical Contacts
12,5 1/2" 2P608-2-4-12GMC
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
2 Electrical Contacts :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 4 2
12,5 1/2" 2P608-4-11/GSMC
Specs
4 x Couplings 1/2":1"-14 UNS MALE ORFS - ISO 8434-3
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2102 g 4.63 lb

For more information contact us: [email protected]
6 4
12,5 1/2" 2P608-4-12S M C
Specs
4 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2187 g 4.82 lb

For more information contact us: [email protected]
6 4
12,5 1/2" 2P608-4-8B M C
Specs
4 x Couplings 1/2":13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2039.4 g 4.5 lb

For more information contact us: [email protected]
6 4
12,5 1/2" 2P608-5-12G M C
Specs
5 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 5
12,5 1/2" 2P608-6-12G M C
Specs
6 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2630 g 5.8 lb

For more information contact us: [email protected]
6 6
12,5 1/2" 2P608-6-12S M C
Specs
6 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2625 g 5.79 lb

For more information contact us: [email protected]
6 6
12,5 1/2" 2P608-6-13/FSMC
Specs
6 x Couplings 1/2":3/4"-16 UNF MALE JIC - ISO 8434-2
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 6
12,5 1/2" 2P608-6-34S M C
Specs
6 x Couplings 1/2":1 - 1/16" - 12 UN FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2776.9 g 6.12 lb

For more information contact us: [email protected]
6 6
12,5 1/2" 2P608-6-8B M C
Specs
6 x Couplings 1/2":13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2460.3 g 5.42 lb

For more information contact us: [email protected]
6 6
12,5 1/2" 3P608-1-5-12GMC
Specs
5 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 5 1
12,5 1/2" 3P608-6-12G M C
Specs
6 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3181 g 7.01 lb

For more information contact us: [email protected]
6 6
12,5 1/2" 3P608-6-12S M C
Specs
6 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 4221 g 9.31 lb
6 6
12,5 1/2" 3P608-A-5-12GMC
Specs
5 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :7 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 5 1
12,5 1/2" 3P608-B-4-12GMC
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
2 Electrical Contacts :7 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
6 4 2
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
08 12.5 1/2" 25 MPa 3625.943 psi 70 18.492 0.01 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
