Product series
P508
Applications
Agriculture Construction Equipment Vehicles & Road Machines

MultiFaster 4 lines, size 08.

Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings Electrical Contacts
12,5 1/2" 2P508-1-2-12GFC
Specs
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Seals: NBR & PUR
4 2 1
12,5 1/2" 2P508-1-2-12SFC
Specs
2 x Couplings 1/2":3/4"-16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 2 1
12,5 1/2" 2P508-1-3-12GFC
Specs
3 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4357.8 g 9.61 lb

For more information contact us: [email protected]
4 3 1
12,5 1/2" 2P508-2-2-12GFC
Specs
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
2 Electrical Contacts :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4267 g 9.41 lb

For more information contact us: [email protected]
4 2 2
12,5 1/2" 2P508-3-12S F C
Specs
3 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 3
12,5 1/2" 2P508-4-12G F C
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4406 g 9.71 lb

For more information contact us: [email protected]
4 4
12,5 1/2" 2P508-4-12N F C
Specs
4 x Couplings 1/2":NPTF 1/2" FEMALE - ANSI B1.20.4
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4406 g 9.71 lb

For more information contact us: [email protected]
4 4
12,5 1/2" 2P508-4-12S F C
Specs
4 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4542.4 g 10.01 lb

For more information contact us: [email protected]
4 4
12,5 1/2" 2P508-4-3/24F C
Specs
4 x Couplings 1/2":M24x1,5 MALE 16S - ISO 8434-1-S
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 4
12,5 1/2" 2P508-4-34S F C
Specs
4 x Couplings 1/2":1 - 1/16" - 12 UN FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 4
12,5 1/2" 2P508-4-F F C
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Seals: FKM
Weight: 4400 g 9.7 lb
* 1 coupler in stainless steel with seals in FKM 3 couplers in steel with seals in NBR-PUR
4 4
12,5 1/2" 3P508-3-12GFATC
Specs
3 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4148 g 9.14 lb

For more information contact us: [email protected]
* The safety lock is on the left side of the block. Also, this part number is equipped with a straight lever on the left side (not a "U" one)
4 3
12,5 1/2" 3P508-4-12G F C
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4264 g 9.4 lb

For more information contact us: [email protected]
* This part number is equipped with a straight "U" lever (R187 mm instead of R290 mm)
4 4
12,5 1/2" 3P508-4-G F C
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 4400 g 9.7 lb
* Right safety lock - Right compact lever This part number is equipped with a shorter lever (R254 mm instead of R290 mm)
4 4
12,5 1/2" 3P508-4-H F C
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Seals: NBR & PUR
* Left safety lock - Left compact lever This part number is equipped with a shorter lever (R250 mm instead of R318 mm)
4 4

Male

Filter items
Units
PartNumber Specs Housings Couplings Electrical Contacts
12,5 1/2" 2P508-1-2-12GMC
Specs
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 2 1
12,5 1/2" 2P508-1-2-12SMC
Specs
2 x Couplings 1/2":3/4"-16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 2 1
12,5 1/2" 2P508-1-3-12GMC
Specs
3 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Seals: NBR & PUR
4 2 1
12,5 1/2" 2P508-3-12S M C
Specs
3 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 3
12,5 1/2" 2P508-4-12G M C
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1922 g 4.24 lb

For more information contact us: [email protected]
4 4
12,5 1/2" 2P508-4-12N M C
Specs
4 x Couplings 1/2":NPTF 1/2" FEMALE - ANSI B1.20.3
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1936 g 4.27 lb

For more information contact us: [email protected]
4 4
12,5 1/2" 2P508-4-12S M C
Specs
4 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 4
12,5 1/2" 2P508-4-34S M C
Specs
4 x Couplings 1/2":1 - 1/16" - 12 UN FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2026 g 4.47 lb

For more information contact us: [email protected]
4 4
12,5 1/2" 3P508-1-3-12GMC
Specs
3 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2428 g 5.35 lb

For more information contact us: [email protected]
2 3 1
12,5 1/2" 3P508-2-12G M C
Specs
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1962 g 4.33 lb

For more information contact us: [email protected]
4 2
12,5 1/2" 3P508-2-B M C
Specs
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2193 g 4.83 lb

For more information contact us: [email protected]
4 2
12,5 1/2" 3P508-3-12G M C
Specs
3 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 2465 g 5.43 lb
4 3
12,5 1/2" 3P508-3-B M C
Specs
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2420.8 g 5.34 lb

For more information contact us: [email protected]
4 3
12,5 1/2" 3P508-4-12G M C
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2944 g 6.49 lb

For more information contact us: [email protected]
4 4
12,5 1/2" 3P508-4-12S M C
Specs
4 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 4
12,5 1/2" 3P508-4-3/24M C
Specs
4 x Couplings 1/2":M24x1,5 MALE 16S - ISO 8434-1-S
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 4
12,5 1/2" 3P508-4-71/12G M C
Specs
4 x Couplings 1/2":BSPP 1/2 FEMALE ORB - JIS B 2351-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 3000 g 6.61 lb
4 4
12,5 1/2" 3P508-4-F M C
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Seals: FKM
Weight: 3000 g 6.61 lb
* No 1 coupler in stainless steel with seals in FKM. No 3 couplers in steel with seals in NBR - PUR.
4 4
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
08 12.5 1/2" 25 MPa 3625.943 psi 70 18.492 0.01 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
