Product series
P4A
Applications
Construction Equipment

MultiFaster 2 lines size 08, 2 lines size 16

Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings Electrical Contacts
12,5 & 25 1/2" & 1" 3P4A-1-3-A F C
Specs
1 x Coupling 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
2 x Couplings 1":BSPP 1" FEMALE - ISO 1179-1
Flow Rate: 150 (l/min) at 0.2 MPa 39.626 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Seals: NBR & PUR
4 3 1
12,5 & 25 1/2" & 1" 3P4A-4-B F C
Specs
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
2 x Couplings 1":BSPP 1" FEMALE - ISO 1179-1
Flow Rate: 150 (l/min) at 0.2 MPa 39.626 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 4

Male

Filter items
Units
PartNumber Specs Housings Couplings Electrical Contacts
12,5 & 25 1/2" & 1" 3P4A-1-3-A M C
Specs
1 x Coupling 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
2 x Couplings 1":BSPP 1" FEMALE - ISO 1179-1
Flow Rate: 150 (l/min) at 0.2 MPa 39.626 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Seals: NBR & PUR
4 3 1
12,5 & 25 1/2" & 1" 3P4A-4-C M C
Specs
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
2 x Couplings 1":BSPP 1" FEMALE - ISO 1179-1
Flow Rate: 150 (l/min) at 0.2 MPa 39.626 (gal/min) at 0.2 MPa
Seals: NBR & PUR
4 4
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
08 12.5 1/2" 25 MPa 3625.943 psi 70 18.492 0.01 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
16 25 1" 25 MPa 3625.943 psi 150 39.626 0.03 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
