Product series
P412
Applications
Agriculture Construction Equipment Industrial Oil&Gas Vehicles & Road Machines Mining

MultiFaster 4 lines, size 12.

Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings
20 3/4" 3P412-4-34G F C
Specs
4 x Couplings 3/4":BSPP 3/4" FEMALE - ISO 1179-1
Flow Rate: 105 (l/min) at 0.2 MPa 27.738 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 5440.8 g 11.99 lb

For more information contact us: [email protected]
4 4
20 3/4" 3P412-4-B F C
Specs
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 5645.4 g 12.45 lb

For more information contact us: [email protected]
4 4

Male

Filter items
Units
PartNumber Specs Housings Couplings
20 3/4" 3P412-4-34G M C
Specs
4 x Couplings 3/4":BSPP 3/4" FEMALE - ISO 1179-1
Flow Rate: 105 (l/min) at 0.2 MPa 27.738 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4456 g 9.82 lb

For more information contact us: [email protected]
4 4
20 3/4" 3P412-4-34S M C
Specs
4 x Couplings 3/4":1 - 1/16" - 12 UN FEMALE ORB - ISO 11926-1
Flow Rate: 105 (l/min) at 0.2 MPa 27.738 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 4418 g 9.74 lb
4 4
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
12 20 3/4" 25 MPa 3625.943 psi 105 27.738 0.02 100 MPa 14503.774 psi 100 MPa 14503.774 psi 110 MPa 15954.151 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
