Product series
P12A
Applications
Agriculture Construction Equipment Industrial Vehicles & Road Machines

MultiFaster 12 lines. 2 lines size 04 (1/4"), 10 lines size 08 (1/2").

Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings
6,3 & 12,5 1/4" & 1/2" 2P12A-0-12-B FC
Specs
2 x Couplings 1/4":7/16"-20 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
10 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 8600 g 18.96 lb

For more information contact us: [email protected]
12 12
6,3 & 12,5 1/4" & 1/2" 2P12A-10-A F C
Specs
10 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
12 10
12,5 1/2" 2P12A-10-C F C
Specs
10 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Seals: FKM
Weight: 14650 g 32.3 lb
* Stainless Steel
12 10

Male

Filter items
Units
PartNumber Specs Housings Couplings
6,3 & 12,5 1/4" & 1/2" 2P12A-10-A M C
Specs
10 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
12 10
6,3 & 12,5 1/4" & 1/2" 3P12A-0-12-B MC
Specs
2 x Couplings 1/4":7/16"-20 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
10 x Couplings 1/2":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
12 12
12,5 1/2" 2P12A-10-C M C
Specs
10 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Seals: FKM
Weight: 8200 g 18.08 lb
12 10
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
04 6.3 1/4" 25 MPa 3625.943 psi 20 5.283 0.008 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
08 12.5 1/2" 25 MPa 3625.943 psi 70 18.492 0.01 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
