Product series
MultiGrease
Applications
Construction Equipment

MultiFaster with a special coupling suitable for machines with a centralized lubrication system.

Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings Electrical Contacts
12,5 1/2" 3P508-A-2-1-A FC
Specs
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 x Coupling 1/2":BSPP 1/8" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :7 Pins
Seals: NBR
* No. 1 greasing line 1/2", Female 1/8" BSPP thread adaptor This part number is equipped with a shorter lever (R250 mm instead of R318 mm)
4 3 1

Male

Filter items
Units
PartNumber Specs Housings Couplings Electrical Contacts
12,5 1/2" 3P508-A-3-A MC
Specs
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 x Coupling 1/2":BSPP 1/8" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :7 Pins
Seals: NBR
* No. 1 greasing line 1/2" whit shunt, Female 1/8" BSPP thread for both inlet and outlet line
4 3 1
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
08 12.5 1/2" 3P 25 MPa 3625.943 psi 70 18.492 0.01 100 MPa 14503.774 psi 100 MPa 14503.774 psi 110 MPa 15954.151 psi
Material:
Aluminium & Steel
Seals:
NBR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
